Forklift Drive Axle

Forklift Drive Axles - A lift truck drive axle is actually a piece of machinery that is elastically fastened to a vehicle framework using a lift mast. The lift mast is connected to the drive axle and is capable of being inclined around the drive axle's axial centerline. This is done by no less than one tilting cylinder. Forward bearing parts combined with rear bearing elements of a torque bearing system are responsible for fastening the drive axle to the vehicle frame. The drive axle can be pivoted round a swiveling axis oriented transversely and horizontally in the vicinity of the rear bearing parts. The lift mast could also be inclined relative to the drive axle. The tilting cylinder is connected to the lift truck frame and the lift mast in an articulated fashion. This allows the tilting cylinder to be oriented nearly parallel to a plane extending from the axial centerline and to the swiveling axis.

Lift truck models like for instance H35, H40 and H45 that are manufactured in Aschaffenburg, Germany by Linde AG, have the lift mast tilt ably mounted on the vehicle framework. The drive axle is elastically attached to the forklift frame utilizing a multitude of bearing devices. The drive axle comprise tubular axle body along with extension arms affixed to it and extend backwards. This kind of drive axle is elastically connected to the vehicle framework by rear bearing parts on the extension arms together with frontward bearing tools situated on the axle body. There are two back and two front bearing devices. Each one is separated in the transverse direction of the vehicle from the other bearing tool in its respective pair.

The drive and braking torques of the drive axle are maintained through the back bearing parts on the framework utilizing the extension arms. The lift mast and the load produce the forces that are transmitted into the roadway or floor by the framework of the vehicle through the drive axle's front bearing elements. It is vital to make sure the components of the drive axle are configured in a rigid enough method to maintain stability of the forklift truck. The bearing elements could minimize small road surface irregularities or bumps during travel to a limited extent and offer a bit smoother operation.
